Medical gas alarm systems are designed to constantly monitor the pressure within a gas system and alert staff to conditions outside normal operating parameters. Amba Medi Nex Engineers deals in Microcontroller based digital gas alarm systems to monitor current status of central Medical Gases supply & Vacuum System and trigger dual alarm (Audio & Visual) in case of any deviation from the predetermined set parameters.

These alarms can be conveniently located to any area/ zone/ ward/ and ICU in consultation with the healthcare personnel to signal the user with an auditory and visual alert of the Medical Gas Pipeline System. Gas Alarm system has been designed for integration with the master alarm of central information system which has 16 zone display facility.

Although nominal pressure is preset in factory, but high and low Alarm triggering range can be varied through reset button in consultation with the health care personnel. Amba Medi Nex Gas Alarm Systems can be ordered for any combination of medical gases including vacuum and configured accordingly to a maximum of six gases in the factory prior to shipment.

External Power adapter that accepts 240V AC (50 Hz) as the input voltage and delivers output voltage of 12V DC, required only for auditory & visual signals. The Auditory signal can be cancelled only by the “mute” button or fault correction and once pressed the audio will remain mute for 15 minutes. However, the red display will blink and continue to indicate abnormality as long as a fault condition exists. Reset is automatic with the correction of the fault condition. Dual Alarm System- Audio Alarm approx- 70 DB Visible

Signals- Green Light “Normal” and Red “High” or “Low” condition. Display Character- 0.5 inch red LED character, two figure for gases and three –figure for vacuum.
